TDZ5-WS Benchtop Low Speed Centrifuge
Centrifuge TDZ5-WS is a hot-selling classic product sold by Cence for many years.
The sturdy mental casing is safe and reliable. Great performance, high quality and other facts make this centrifuge popular more than 20 years.
Equipped with a variety of brackets and adapters, it is an ideal choice for clinical testing and laboratory analysis.
Product Advantages
1. Various brackets and adapters are available.
2. Microprocessor control, DC brush-less motor.
3. RCF value can be calculated automatically.
4. Special damping structure to reduce vibration.
5. Countdown time displayed by seconds if the centrifugation time is less than 1min.
Technical Parameters
|
Model |
TDZ5-WS |
|
Order No. |
0205174000 |
|
Max. speed |
5000r/min |
|
Max. RCF |
4390xg |
|
Max. capacity |
4x250ml |
|
Speed accuracy |
±30r/min |
|
Time setting range |
1min to 99min |
|
Noise |
≤65dB(A) |
|
Power supply |
AC220V±22V 50/60Hz |
|
Power consumption |
400W |
|
Dimension (WxDxH) |
450x545x380mm |
|
Packing dimension (WxDxH) |
547x727x432mm |
|
Weight |
40kg |
Rotor Options
|
Rotor No. |
Rotor type |
Max. speed (r/min) |
Max. RCF(xg) |
Capacity |
|
No.1 |
Swing rotor yoke |
5000 |
4390 |
4x100ml |
|
Bracket |
5000 |
4390 |
4x100ml |
|
|
Adaptor |
5000 |
4390 |
4x50ml |
|
|
4x50ml(conical) |
||||
|
4x30ml |
||||
|
4x20ml |
||||
|
4x15ml |
||||
|
4x15ml(conical) |
||||
|
4x3x5ml vacuum blood collection tube |
||||
|
4x2x10ml |
||||
|
4x4 hematocrit tube |
||||
|
4x3x1.5ml |
||||
|
No.2 |
Swing rotor yoke |
4000 |
2810 |
4x2x100ml |
|
Bracket |
4000 |
2810 |
4x2x50ml |
|
|
Bracket |
4000 |
2810 |
4x2x100ml |
|
|
Adaptor |
4000 |
2810 |
4x2x50ml |
|
|
4x2x15ml(conical) |
||||
|
4x2x50ml(conical) |
||||
|
4x6x5ml vacuum blood collection tube |
||||
|
4x2x30ml |
||||
|
4x4x10ml |
||||
|
4x2x20ml |
||||
|
4x8 hematocrit tube |
||||
|
4x2x15ml |
||||
|
4x3x1.5ml |
||||
|
Bracket |
4000 |
2810 |
4x8x15ml |
|
|
Adaptor |
4000 |
2810 |
10ml/7ml/5ml |
|
|
No.3 |
Swing rotor yoke |
4000 |
2200 |
2x2x96 well |
|
Microplate bucket |
4000 |
2200 |
2x6 MTP 2x2 DWP 2x1 filter kit |
|
|
No.4 |
Swing rotor yoke |
4000 |
3000 |
4x250ml |
|
Round bucket |
4000 |
3000 |
4x250ml |
|
|
Adaptor |
4000 |
3000 |
4x1x100ml |
|
|
4x1x50ml(conical) |
||||
|
4x1x50ml |
||||
|
4x4x20ml |
||||
|
4x4x15ml(conical) |
||||
|
4x6x15ml |
||||
|
4x7x10ml |
||||
|
4x10x5ml |
||||
|
4x8x1.5ml |
||||
|
Rectangular bucket |
4000 |
3000 |
4x250ml |
|
|
Adaptor |
4000 |
3000 |
4x1x250ml(flat) |
|
|
4x4x50ml(conical) |
||||
|
4x7x15ml(conical) |
||||
|
4x9x10ml |
||||
|
4x9x5ml |
||||
|
4x15x1.5ml |
